Rythmik Audio F18 SE
₹2,411,402.00
18″ sealed audiophile subwoofer
This product can be arranged on request. Call us for pricing details to place your order
- Description
- Additional information
- Reviews (0)
Description
Finesse meets brute force
Our servo technology is scalable to all subwoofer designs as well as driver size. F18 is our largest single driver sealed subwoofer to meet the needs for a high power home theater solution that retains the dynamic, accurate, and deep bass that we have become known for. Its max output at 20hz is at least 8db higher than that of our 12″ sealed model F12 and more than 11db higher than our competitior’s 12″ model SB** measured by data-bass.com. The amplifier is based on Hypex audiophile class-D module. With the combination of the servo feedback and stiff aluminum cone, we have achieved lower distortion than competitor’s 18″ servo subwoofers (DD18+) with the same or even higher maximum SPL output from 10hz to 100hz , as tested at data-bass.com. In fact, F18 has recorded the lowest THD numbers at the maximum SPL output than any other subs tested. Our servo technology is scalable to all subwoofer designs as well as driver sizes.
Direct Servo Technology
All our subwoofers use our patented Direct Servo technology. The servo enables precise control over the cone which is essential for tight, dynamic and accurate bass. It also counteracts many different driver non-linearities and allows us to use lighter drivers which avoid the need for excessive amounts of amplifier power.
Some of the benefits of Direct Servo include:
- Dramatic boxy sound reduction of the re-radiation of bass from inside the box
- Thermal compression are eliminated under normal operation
- Higher efficiency allowing output which would normally require a more powerful amplifier
- Deep bass extension can be achieved using a low mass driver with superior transient response
- Mechanica creepl memory effects are reduced, further improving transient response
- The (temperature-independent) effective in-box Q value is 0.25 (0.1 for driver itself) resulting in much tighter and accurate bass than conventional designs of in-box Q value of 0.75-0.80 (and even higher when voice coil becomes hot)
Specifications
| Driver | DS1820 18″ high excursion with custom sensing coil |
| Driver materials | One piece black anodized dish aluminum with rubber surround |
| Cast aluminum basket | |
| Multiple aluminum flux de-modulation shorting rings | |
| Amplifier | 900W RMS Hypex class-D patented servo controlled |
| Dimensions | 20-1/2″(W) x 20-1/2″ (H )x 21″(D) – (23″ D with grille and heatsink) |
| Shipping Weight | 140 lbs (125lbs gross) |
| Frequency Response | 14 – 200 Hz (0db/-2db) with LFE inputs |
| 10 – 250Hz (+/-3db) with LFE inputs | |
| 14 – 90 Hz (-2 dB @ 14 Hz) with LINE IN inputs | |
| Crossover slope | Selectable 12 or 24 dB / octave (PEQ and XLR versions) |
| Crossover range (Low pass) | 25 – 100Hz |
| Rumble Filter (High pass ) | 12 Hz 18 dB / octave (-6db @10hz) |
| Phase response | 90 degrees phase shift at 20 Hz (measuring mic has 18 degrees shift) |
| Phase adjustment | 0 – 180 degrees continuously variable |
| Bass damping factor settings | high (Q=0.5), med (Q=0.7), and low (Q=1.1) |
| Finishes | Available in black oak and black matte vinyl |
| Warranty | 5 years warranty on driver and 3 years on electronics |
| 45 day satisfaction guarantee |
